In the marine industry, ship hull thickness measurement is a very important procedure that requires non-destructive testing (NDT) to identify the current thickness of the hull plates of a vessel. This is an important process to determine the structural soundness of a ship and is vital in promoting marine safety, efficiency, and regulatory standards. Ships are subjected to corrosive conditions as they are always in a risky position to become corroded; this is because they are operated in adverse environments. This allows the marine, offshore, and oil and gas companies to proactively identify any areas of concern, avert structural breakdowns, and keep their vessels at sea with the measurement of hull thickness. This is one of the pillars of maritime assets management today.

What is Ship Hull Thickness Measurement?

Ship hull thickness measurement is a special inspection that measures the volume of material lost through the hull of the ship as a result of corrosion, abrasion, or other wear and tear. It plays an important role in the maintenance program of a vessel, especially when dry-docking. The data serves to guide the engineers and surveyors in deciding whether the hull is operating within the acceptable limits as stipulated by classification societies. This is needed to prevent corrosion, cracks, and eventually, disastrous structural collapses, which would pose hazards to the vessel, the crew, and cargo.

Why Hull Thickness Measurement is Important

Frequently, measuring the hull thickness is not merely a formality; it is a requirement that will be explained in the following reasons:

• Crew and Cargo Safety: This is the most important because it is necessary to check the integrity of the vessel structure. A damaged hull may cause leakages, floods, or even ship loss.
• Compliance: Compliance is a necessary regulation to meet the standards established by the International Maritime Organization (IMO), International Association of Classification Societies (IACS), and individual class societies such as DNV, ABS, and Lloyd’s Register.
• Cost Savings: Early detection will help shipowners plan small, limited repairs before they do massive overhauls or repairs in an emergency.
• Vessel Lifespan, Extending: Vessel life can be greatly extended by being proactively maintained using correct thickness measurements to ensure the vessel lasts as long as possible.

Methods of Ship Hull Thickness Measurement

The main technique to measure ship hull thickness is the Ultrasonic Thickness Measurement (UTM). UTM is a very powerful Non-Destructive Testing (NDT) technology that can measure the thickness of material with high-frequency sound waves without destroying the property.

• Ultrasonic Thickness Measurement (UTM): This is the simplest. An ultrasonic pulse is sent through the hull plate using a probe, and the duration in which the pulse takes to bounce off the inner surface is measured and translated into a thickness reading.
• Rope Access and Diving-Based Inspections: In places that are difficult to reach, or during in-service inspections, the UTM can be completed by rope access technicians or certified divers.
• Tools and Equipment: The process is dependent on special tools, such as an ultrasonic thickness gauge, calibrated probes, and data logging equipment.

Step-by-Step Process

A comprehensive survey of hull thickness is carried out in a quality-assured process.

1. Pre-inspection Survey: This is the initial survey undertaken by a surveyor to determine the sections of the hull to be tested, usually according to a vessel’s history and class society mandate.
2. Cleaning and Surface Preparation: The hull surface should also be cleaned of marine growth, paint, and rust before testing to allow an adequate connection of the ultrasonic probe.
3. Conducting Ultrasonic Testing: An authorized technician then uses a coupling gel and lays the ultrasonic probe on the hull in order to measure thickness readings precisely.
4. Recording and Analyzing Results: All the data is carefully documented and compared with the initial hull specifications to spot any areas of concern.
5. Class Approval Reporting: A comprehensive report is prepared containing the results and provided to the classification society of the vessel to be reviewed and subsequently approved.

Regulatory Standards and Compliance

Ship safety compliance surveys are regulated by the following major international bodies:

• International Maritime Organization (IMO): Establishes international standards of ship safety and environmental safety.
• IACS & Classification Societies: Insurers such as DNV, ABS, Lloyds Register, and Bureau Veritas have elaborate rules in regard to the construction and maintenance of vessels, including minimum thickness.
• Port Authority Regulations: Local port authorities can also impose certain conditions on the vessels that operate within their area.

Challenges in Hull Thickness Measurement

However, even though this is an important process, it is not devoid of certain challenges:

• Accessing Hard-to-Reach Areas: Reaching every part of the hull, particularly submerged areas, may be challenging and may need specialized skills or equipment.
• Corrosion Under Insulation/Paint: This type of corrosion is not easily noticeable without sophisticated means and proper surface preparation.
• Time and Cost Factors: An extensive survey takes a considerable amount of time and manpower, which can be a costly affair.
• Required Specialized Equipment: Precise measurements require specialized equipment that is well-calibrated and used by qualified technicians.

Best Practices for Effective Hull Thickness Surveys

Good practices to have a successful and effective survey include:

• Scheduled Inspections: Have hull thickness surveys as part of your routine dry-docking procedures as mandated by class societies.
• Employ Qualified Technicians: NDT technicians who have experience in marine-related inspections.
• Keep Good Records: Generally, have good records of all inspection reports and findings to aid in future audits and maintenance scheduling.
• Rope Access/Diving: Take advantage of these techniques to reach hard-to-reach places effectively and also provide a thorough check.

Role of Professional Testing & Inspection Services

Surveys of the hull thickness are best outsourced to a professional service provider as a way of assuring truth and reliability. Astar Testing & Inspection Company is one of the companies that provide certified hull thickness measurement on innovative NDT methods. They have specialized equipment and experience that ensure an accurate analysis, ensuring that shipowners can comply with regulations and preserve assets.

Conclusion

The thickness of the hull of the ship is a factor of ship safety and management that cannot be compromised. Regularly carrying out such important surveys, shipowners and operators will be able to prevent major accidents in the most proactive way, as well as make sure that all regulations are followed, and will make great cost savings by increasing the life of their ships. The most effective solution is to place your fleet in the hands of an honest inspection service.

Get a reputable inspection partner to conduct hull thickness surveys.

Frequently Asked Questions (FAQ)

1. What does a ship hull thickness measurement mean?

Ans: Ship hull thickness checking is a procedure used to examine the steel plating of a vessel hull in order to identify corrosion, wear or damage. It guarantees that the ship is structurally sound, and up to global standards.

2. So why measure hull thickness?

Ans: It assists in the safety of the vessel, structural failure prevention, classification societies (DNV, ABS, BV, Lloyds Register) compliance, and eliminates expensive repairs due to timely detection of problems.

3. What is the way to measure ship hull thickness?

Ans: Ultrasonic Thickness Measurement (UTM) is the most prevalent technique that uses a non-destructive testing (NDT) method to give precise information without causing any damage to the steel structure.

4. What is the frequency of hull thickness measurement of a ship?

Ans: The vessels are usually expected to have their thickness measured during special surveys every five years or as per the class societies’ stipulations. Further examinations might be required in case of possible corrosion or damage.

5. Who should do the hull thickness measurement?

Ans: The hull thickness measurements can be performed by certified NDT technicians authorized by classification societies. Collaboration with professional companies leads to accuracy and compliance standards.

6. What would be the result of a ship failing on a thickness test?

Ans: A major thinning or damage found needs to be repaired or steel replaced before the ship is reinstated to service and granted the class approval again.

7. Is it possible to measure the hull thickness in the water?

Ans: Yes. When used together with diving inspections and ROVs, it is possible to perform ultrasonic testing on submerged sections of the hull, which saves time and eliminates the delays associated with dry-dock inspections.
